APPENDIX B: ELECTRICAL AND DATA CONNECTIONS
HF-2500A HIGH FREQUENCY WELD CONTROL
B-8 990-371
Modification of I/O Configuration:
The inputs of this unit are grouped into two major blocks, which can be independently configured.
SCHEDULE INPUTS
Common Input Pin Number
I/O COMMON
WELD ABORT 10
WELD / NO WELD 13
SCHEDULE 0 (2
0
) 24
SCHEDULE 1 (2
1
) 25
SCHEDULE 2 (2
2
) 26
SCHEDULE 4 (2
3
) 27
SCHEDULE 8 (2
4
) 28
SCHEDULE 16 (2
5
) 29
SCHEDULE 32 (2
6
) 30
WELD INHIBIT 31
FOOT SWITCH / FIRE SWITCH INPUTS
Common Inputs Pin Number
FS1/FS2/FIRE_COM
FIRE_1 11
FOOT_1 16
FOOT_2 17
CURRENT STOP 32
