HF-2500A HIGH FREQUENCY WELD CONTROL
990-371 3-1
CHAPTER 3
System Configuration
Section I: Menus
Before You Start
Configuration is simply a matter of selecting various MENU options so the Power Supply will work with
all the components of your welding system.
• Verify that all connections have been made according to the instructions in Chapter 2,
Installation and Setup.
• Turn the Power Supply ON.
• Turn the shop air supply ON.
Overview
You program the system settings of the Power
Supply
through the MAIN MENU screen and its
sub
-menus. You go to the MAIN MENU screen by
pressing the
MENU key on the front panel of the
Power Supply
.
All of the menu screens have similar prompts
that
tell you
how to go to a function on the menu
and/or get to the next menu.
<MAIN MENU>
1. SETUP 6. COMMUNICATIONS
2. WELD COUNTERS 7. RELAY
3. COPY A SCHEDULE 8. RESET DEFAULTS
4. CALIBRATION 9. CHAIN SCHEDULES
5. SYSTEM SECURITY
Number Select an item
• At the NUMBER Select an item prompt, use the numeric keypad to select one of the functions on the
menu.
• Press the down keys to go to the next or previous menu. Each additional menu gives you
choices for additional functions.
• Press the MENU key to return to the main menu.
Main Menu
1. SETUP
From the MAIN MENU screen, press 1 to go to the
SETUP 1
screen.
The
SETUP 1 screen is shown on the right with
typical settings.
<SETUP, page 1 of 3>
1. FOOTSWITCH WELD ABORT : OFF
2. SWITCH DEBOUNCE TIME : 10 ms
3. FIRING SWITCH : AUTO
Number Select an item, Page, RUN or MENU
