HF-2500A HIGH FREQUENCY WELD CONTROL
990-371 1-1
CHAPTER 1
Description
Section I: Features
The HF-2500A Power Supply precisely controls and monitors both electrical and mechanical weld
parameters.
Power Supply Features
● Constant Current, Voltage & Power
modes
● Monitor Energy and Resistance
● Force Control
● Monitor Displacement and Force
Weld Quality Process Tools
● Envelope Function
● Active Part Conditioning
● Pre-weld Check
● Weld to Limits
D
escriptions of the various control modes and
process tools
are located in Chapter 3, System
Configuration,
and Chapter 4, Introduction to
Feedback Modes and Weld Monitoring
.
Detailed instructions
on using these features are
located
in Chapter 5, Operating Instructions.
This manual covers the following models:
MODEL NUMBER STOCK NUMBER
HF-2500A/240 1-315-02
HF-2500A/400 1-315-02-01
HF-2500A/480 1-315-02-02
NOTE: For the rest of this manual, the AMADA WELD TECH HF-2500A High Frequency Weld
Control will simply be referred to as the Power Supply.
