CHAPTER 2: INSTALLATION AND SETUP
HF-2500A HIGH FREQUENCY WELD CONTROL
2-2 990-371
Utilities
Power
Because of the different electrical requirements for the countries in which the Power Supply is used, the
Power Supply is shipped without a power cable connector. The required connections for your power cable
connector are described in Appendix B, Electrical and Data Connections. Input power requirements for
the Power Supply are as listed below.
Power Input Specifications
HF-2500A
Model
Input
Voltage,
50-60 Hz,
3 phase
(Vrms)
Circuit
Breaker
Current
(A rms)
Copper Wire
Gauge,
7 strands
(AWG)
Wire Dia
(mm)
Fuses F1, F2
Amps/
Volts
AMADA WELD
TECH P/N
HF-2500A/240 240 25 10 2.5 6.3 330-096
HF-2500A/400 400 20 10 2.5 3.15 330-095
HF-2500A/480 480 13 10 2.5 3.15 330-097
Compressed Air and Cooling Water
If you require compressed air and cooling water service for the weld head, please refer to the weld head
manufacturer’s user’s manual for service specifications.
