CHAPTER 3: SYSTEM CONFIGURATION
HF-2500A HIGH FREQUENCY WELD CONTROL
3-18 990-371
See Chapter 4, Using Feedback Modes and Weld Monitoring for a detailed description of monitor and
energy limits operation.
Alarm State
The Power Supply automatically recognizes
many alarm conditions. The example
WELD
SWITCH IN NO WELD POSITION
alarm screen
shown at the right is displayed when you attempt
to initiate a weld with the
WELD/ NO WELD switch
in the
NO WELD position.
