APPENDIX E. COMMUNICATIONS
HF-2500A HIGH FREQUENCY WELD CONTROL
E-18 990-371
WELD STATUS CODES
Number Status Message
65
SCHEDULES ARE RESET
66
SYSTEM PARAMETERS ARE RESET
67
PULSE 1 LOWER LIMIT REACHED
68
PULSE 1 UPPER LIMIT REACHED
69
WELD TIME TOO SMALL
70
NOT USED
71
CURRENT2 > UPPER LIMIT
72
CURRENT2 < LOWER LIMIT
73
VOLTAGE2 > UPPER LIMIT
74
VOLTAGE2 < LOWER LIMIT
75
POWER2 > UPPER LIMIT
76
POWER2 < LOWER LIMIT
77
RESISTANCE2 > UPPER LIMIT
78
RESISTANCE2 < LOWER LIMIT
79
INHIBIT 2ND PULSE
80
WELD STOP - LIMIT REACHED
81
SYSTEM ERROR: BUS ERROR
82
SYSTEM ERROR: SOFTWARE INTERRUPT
83
SYSTEM ERROR: ILLEGAL INSTRUCTION
84
SYSTEM ERROR: DIVIDED BY ZERO
85
SYSTEM ERROR: SPURIOUS INTERRUPT
86
COOL TIME MINIMUM
87
TEST WELD? [MENU]=NO [RUN]=YES
88
NOT USED
89
NOT USED
90
NOT USED
91
NOT USED
92
NOT USED
Command
SCHEDULE schedule_number <crlf><lf>
Control State
Any
Description
Returns the current schedule number to the host.
S
chedule_number may be any number from 0
to 99.
