APPENDIX B: ELECTRICAL AND DATA CONNECTORS
UB25 LINEAR DC RESISTANCE WELDING CONTROL
990-665 B-11
AC Input Power Connection
AC INPUT POWER CONNECTION SPECIFICATIONS
MODEL TERMINAL MAXIMUM VOLTAGE MAXIMUM CURRENT
UB25
Hot
132 volts 15 amps
Neutral
-- --
Ground
-- --
UB25/230
Hot
265 volts 10 amps
Neutral
-- --
Ground
-- --
GROUND
NEUTRAL
HOT
