Chapter 1 — Introduction 7
Filter Descriptions
IntelleCord and Smart Search filters are nearly identical in con-
figuration and operation. IntelleCord filters are used on live
images; Smart Search filters are used to search the image data-
base. The three filters are described below. The name of the
Smart Search filter (if different) is in parentheses.
Motion Detection
The motion detection filter identifies movement in the target
area. Since the target area can be configured up to a 78x28 grid,
you can check for motion at any of nearly 2,200 target points.
The perimeter protection (perimeter violation) filter identifies
movement across a target boundary.
Perimeter Protection
(Perimeter Violation)
Light Change
The light change filter identifies light level changes in the tar-
get area (light to dark or dark to light).
Playback
The Intellex unit lets you quickly and easily search for and
play back images without interrupting image recording.
• Search according to date/time, camera and alarm criteria.
• Search using Smart Search filters.
• Play back video segments using the Play/Pause screen
control.
• Play back images in forward or reverse sequence at a vari-
ety of speeds, even one image at a time.
• Use image enhancement tools (zoom, brightness/contrast,
color, balance light, edge detect, enhance light, noise re-
duction, sharpen, smooth) before printing an image or sav-
ing it to a diskette.
Unit Configuration
The Intellex unit provides menus and screens for quick
configuration. You can assign names for the cameras and alarm
inputs, configure its response to alarms and configure its record
operation and display settings.
