Chapter 3 — Playback Operation 61
Motion Detection: (camera name) — Indicates the camera
name.
Image Area — This area of the screen displays a camera im-
age and provides a reference when configuring the filter.
Active Zone — Use the following options to configure the
target area. This area can be nearly any shape or size.
Activate — Use this option to activate a specific target area.
Deactivate — Use this option to deactivate a previously
activated target area.
Restore — Click to restore the target area to its dimen-
sions before any changes.
Clear — Click to erase all targets in the active zone.
Motion Detection
Use the Motion Detection screen to configure the target area
for the motion detection filter. Once configured, the filter se-
lects video segments with movement in the target area.
After you select the Motion Detection filter and click the Setup
button, the Motion Detection screen appears.
