20 Intellex
®
Operating Instructions
CONTROLLING
IMAGE DISPLAY
Image display is located in the central area of the screen, where
the unit displays images. The image area is affected by the
following:
• Screen format
• Image area popup menu
• Image area zoom
• Full-screen operation
• Camera sequencing
• Live monitor (optional)
• Unit schedule
Screen Format
You can select from the following four screen formats:
Click this button to select the single window (1x1) format. The
camera assigned to this format will display. In this format, only
one camera can be displayed at a time.
You can also click any camera button to display a camera in
this format.
Click this button to select the four-window (2x2) format. The
cameras assigned to this format will display. In this format, up
to four cameras can be displayed together.
Click this button to select the nine-window (3x3) format. The
cameras assigned to this format will display. In this format, up
to nine cameras can be displayed together.
Click this button to select the 16-window (4x4) format. The
cameras assigned to this format will display. In this format, up
to 16 cameras can be displayed together.
See Display Setup in the Intellex Installation Instructions for more
information.
NOTE: You must close all open screens (except playback) be-
fore changing the screen format.
