Chapter 2 Basic Live Operation 19
11. 1x1 Click to select the single window format (1x1). Only
one camera can be displayed at a time unless you start
camera sequencing. See Screen Format and Camera Sequenc-
ing for more information.
12. 2x2 Click to select the four-window (2x2) format. Up to
four cameras can be displayed at the same time. See Screen
Format for more information.
13. 3x3 Click to select the nine-window (3x3) format. Up
to nine cameras can be displayed at the same time. See
Screen Format for more information.
14. 4x4 Click to select the 16-window (4x4) format. Up to
16 cameras can be displayed at the same time. See Screen
Format for more information.
15. Status Click to display the unit’s status screen. See Re-
viewing Unit Status for more information.
16. Seq (Sequence) Click to display cameras sequentially.
See Camera Sequencing for more information.
17. Full Scrn Click to hide the controls and indicators and
to display the current images full-screen in the selected
screen format (see Full-Screen Format).
18. Search Click to search the image database for specific
video images.
19. Utility Click to access the Utility Options screen (see Util-
ity Options).
20. Archive Click to access the Archive Options screen (see
Archive Operation).
21. Setup Click to access the system configuration options
(see Chapter 4 — Intellex Setup Options in the Intellex Instal-
lation Instructions).
22. Help Click to display online help information.
