26 Intellex
®
Operating Instructions
Unit Schedule
Images from cameras that are disabled in the schedule will
not display. This helps the user monitor cameras that are be-
ing recorded. For more information, see Schedule Setup in the
Intellex Installation Instructions.
If a dome controller (Sensormatic VM16 or American Dynam-
ics ADTT16) is connected, you can use it to display a specific
camera, change the display format (1x1, 2x2, 3x3, 4x4) or se-
quence cameras (live mode only). Refer to the dome controller
instructions for more information.
Dome Controller (Optional)
If an optional live monitor is installed, the unit displays all
live images continuously on the optional monitor. Live dis-
play commands, such as selecting a camera or a screen for-
mat, appear immediately on the optional monitor.
Live Monitor (Optional)
