24 Intellex
®
Operating Instructions
Full-Screen Operation
Use the full-screen option to hide the screen controls and dis-
play live images full-screen in the selected screen format.
NOTE: Image resolution does not increase; images are sim-
ply displayed over a larger area.
To display a format full-screen:
1. Select the screen format: 1x1, 2x2, 3x3 or 4x4. The screen
format changes.
2. Click the Full Scrn button. The screen controls disappear
and the screen format fills the display.
To change the screen format:
1. Click the right mouse button. The Image Area Popup menu
appears.
2. Select Mode. The unit displays a list of screen modes:
Single, 2x2, 3x3, 4x4.
3. Select the desired screen format. The unit immediately
changes the image area.
NOTE: When zooming to a desired area, the unit maintains a
4:3 (width-to-height) ratio. If you drag tall and thin, the
selected area will not be tall, but will maintain the gen-
eral shape of the screen. Likewise, if you drag short
and wide, the selected area will not be wide, but will
maintain the general shape of the screen.
2. To enlarge an area of the image, click and drag the mouse
pointer over the area to enlarge. As you drag the mouse,
the pointer changes to .
3. As soon as you release the mouse button, ZOOM appears
on the screen and the pointer changes to .
4. To return to the 1x1 format, click the image area.
5. (2x2, 3x3 or 4x4 format only) To return to the previous for-
mat, click the screen again.
