PN 903-8797, Rev A
Alarm LED Status
The LEDs on the User Interface are numbered 1–7, from left to right. A lit LED
indicates that the condition associated with the LED currently exists. Four (4)
of the seven (7) LEDs indicate the status of corresponding alarms set by four
alarm relay contacts (two LEDs and their associated alarm relay contacts are
not currently used). The alarm setpoint values for the HCDP temperature are
preset at the factory, but can be changed in the eld.
The conditions which dene the Warning and Fault alarms are part of the
built-in, continuous diagnostics function. The HCDP temperature alarms will
be set at the end of the Cooling Stage, if the conditions that trigger the alarm
are present. The remaining alarms are set at the end of the stage where the
problem occurred.
The LEDs and their corresponding conditions when turned On are:
LED # Setpoint By Condition Existing When LED Turned On
1 User The Hydrocarbon Dewpoint temperature O-Spec Alarm is
disabled (Stat\History : En\Dis Alrm?).
2 Diagnostics Fault Alarm: Analyzer in Standby Mode – Immediate Service
Required (review SCode and XSCode in the Stat\History
menu to gather information before contacting AMETEK). The
alphanumeric display will also ash to alert the operator to this
condition.
3 Diagnostics Warning Alarm: Analyzer reporting an abnormal condition –
Investigation Required (review SCode and XSCode in the Stat\
History menu and attempt to correct the problems).
4 Diagnostics Hydrocarbon Dewpoint temperature Not Found (NoD), or
Purging/Hold Stage Is In Progress (Pur). This setting is made in
the ApplicCFG : UsrRelay menu.
See also the UsrRelay description under “Working in the
Application Conguration Menu” in Chapter 3.
5 User Reserved for Water Content OSpec Alarm setpoint. Currently
Not Used.
6 User The current Hydrocarbon Dewpoint temperature is higher
than the Hydrocarbon Dewpoint temperature O-Spec Alarm
setpoint value (ApplicCFG : HCDPA). This alarm will only be
seen if the O-Spec Alarm is enabled in the Stat\History
menu (LED 1 is O when the O-Spec Alarm is enabled).
7 User Reserved for Water Dewpoint temperature OSpec Alarm
setpoint. Currently Not Used.
Maintenance and Troubleshooting | 4-39
