PN 903-8797, Rev A
Displayed Signals (RUN Menu Scroll Sequence – Quick
Reference)
Detailed information about the signals that are displayed on the User
Interface can be found in Chapter 3 (see “Working in the RUN Menu”).
The RUN menu scrolls automatically and displays, continually, in the following
order:
Displayed
Abbreviation Description Metric Units Imperial Units
M241 Vx.xx Firmware Version x.xx
(Displayed only in rst scroll cycle fol-
lowing a power-up or reset.)
— —
RT Run Time (Days:Hours:Minutes) 000 00:00 000 00:00
Stage Stage of Dewpoint Cycle (Purging/Hold, Cooling, or Warming)
PTime Purge Time
(Displayed only if measuring cycle is in
Purging/Hold Stage.)
minutes minutes
WDP* External Water Dewpoint Temperature < -40.0 °C <40.0 °F
HCDP Hydrocarbon Dewpoint Temperature < -40.0 °C <40.0 °F
WCt** External Water Content <0.0 mg/m
3
(PPMV or PPMW)
<0.0 lb/MMcf
(PPMV or PPMW)
MTemp Mirror Temperature 21.3 °C 70.4 °F
WMir Water Phototransistor Signal 59 59
HCMir Hydrocarbon Phototransistor Signal 103 103
*External Water Dewpoint Temperature (optional).
**External Water Content (optional).
Installation and Start-Up | 2-29
