Uncrating and Inspecting the Analyzer
The analyzer and its sample system is shipped pre-mounted on a backpan,
either alone in a crate or in a crated weatherproof shelter. Upon receiving the
analyzer, remove the shipping crate and check the exterior of the shelter and/
or analyzer for damage. Open the shelter and verify its internal components
are secure and there is no physical damage.
Remove the M10 screw from the analyzer’s Electronics Enclosure and open the
enclosure. Verify its internal components and wiring are secure and there is no
physical damage.
The Heatsink/Measuring Cell Assembly is shipped in a separate box. Remove
the shipping crate and check it for any physical damage.
Avoid damaging the analyzer’s piping and instrumentation by lifting
it out of its shipping crate using only its backpan. DO NOT use any
piping or instrument to lift.
The analyzer and its backpan weighs approximately 60 kg (132 lb).
Use caution when lifting it from its crate.
After the inspection, use a soft, non-abrasive cloth to gently clean the
joining areas (amepaths) of the enclosure and its door. Replace and
tighten at least one M10 screw (if installing immediately) – this will
keep the enclosure secure and will prevent damage to the amepath.
If the Heatsink/Measuring Cell Assembly is not being installed at this
time, store it in its shipping box until it will be installed.
