PN 903-8797, Rev A
Viewing Current Alarm Messages
If any alarms have been detected by the analyzer, the corresponding LED on
the User Interface will be On. Any current alarm messages can be viewed from
the SCode or XSCode sub-menus.
To view the current status of alarm messages (SCode or XSCode) detected by
the diagnostics function:
1. From the RUN menu, press once to view the Stat\History main menu
screen.
2. Press repeatedly until you are viewing the SCode screen.
If you wish to view the XSCode, press again.
3. To view the primary status codes from either screen, press the ‘+’ or ‘–’ but-
ton.
If the alarm is current, its description will be displayed next to its associ-
ated error code number (e.g., “3 w No HC DP”). If the alarm condition does
not exist, “OK” appears next to its associated number (e.g., “SCode.# OK”,
where ‘#’ is the error code number corresponding with the SCode mes-
sage).
4. To back out of either of these screens, press if you wish to view other
Stat\History sub-menus, or press to go to another main menu.
Maintenance and Troubleshooting | 4-45
