PN 903-8797, Rev A
Checking the Fuses
Verify that the installed fuses are correct for the operating voltage, and com-
pare them to the fuse holders within the Electronics Enclosure (individually
labeled). At the front of each fuse holder on the upper side is a tab that proj-
ects upwards. To access the fuses, pull the tab outward.
After checking and replacing the fuse, close the fuse tab, pressing it rmly to
ensure it is fully closed.
These fuse ratings are necessary to maintain certication. For ordering
information, see “Spare Analyzer Fuses” in Chapter 4.
See Fuse Ratings table
in Figure 2-3.
Installation and Start-Up | 2-17
