Ametek 241CE II User Manual

PN 903-8797, Rev A
Working in the Conguration Menu
The Conguration (MonitorCFG) menu allows you to customize unit-specic
parameters.
To view the MonitorCFG menu, press  until MonitorCFG appears. To view
the sub-menu items within this menu, press . Enter the password at the
“Passcode2?” prompt to view the MonitorCFG menu.
The MonitorCFG sub-menu items (listed in their viewing order) and their
descriptions are:
Do not change parameters marked ‘*’ (under “Description”) unless
instructed to do so by an AMETEK service representative. Doing so will
result in incorrect measurements and readings.
Sub-Menu Item Description
Passcode2? This prompt asks to enter Passcode2 to access the MonitorCFG menu (the factory default
password is ‘- - - -’). Enter this password to view and/or change the parameters in this menu.
Water Measurement
Option
The Water Measurement Option sub-menu allows you to select the type of information
you wish to display. Only one of the options can be selected at any time. Note that “Water
Measurement Option” is not displayed; only the current setting will be displayed (e.g.,
H2O DP:EXT). The available options that can be selected include:
• H2O DP:EXT (Water Dewpoint, external measurement – requires external water signal).
• H2O CT:EXT (Water Content, external measurement – requires external water signal).
• H2O DP:INT (Water Dewpoint, internal measurement).
• H2O DP:DISAB (Water Dewpoint, disabled).
Note:
If you change the Water Measurement Option parameter, you will also have
to congure the analyzer to display the associated units of measurement
from the Options code sub-menu, depending on the information you want
to be analyzed and displayed. These changes are required to ensure accurate
representation of the output signals you require. Details about these changes are
described below.
If changes are made to the Water Measurement Option parameter, you will also have to change
the Options code parameters:
• If H2O DP:EXT is enabled, select an option from the Options code sub-menu:
- DP&m (dewpoint, metric units).
- DP&i (dewpoint, imperial units).
• If H2O CT:EXT is enabled, select an option from the Options code sub-menu:
- WC&m (water content, metric units).
- WC&i (water content, imperial units).
- PMVm (parts per million by volume, metric units).
- PMVi (parts per million by volume, imperial units).
- PMWm (parts per million by weight, metric units).
- PMWi (parts per million by weight, imperial units).
(Continued next page)
A password is required
to access the MonitorCFG
menu.
3-18 | 241CE II Hydrocarbon Dewpoint Analyzer
