PN 903-8797, Rev A
Working in the Dierent Menus
While working from the User Interface, there are four main modes (menus) of
operation. Press to scroll through the Main Menu items.
Viewing and entering data is done using the push-buttons for all menus and
sub-menus, which are described in the following pages.
Working in the RUN Menu
The RUN Menu (or RUN Mode) is the normal operating mode. When the ana-
lyzer is started, the RUN Mode is the default interface. The User Interface will
remain in RUN Mode unless you change it to another menu. To return to the
RUN menu at any time, press until “Run” appears.
The software will revert back to the RUN menu if none of the buttons
are pressed within 2 minutes.
The rst cycle of signals displayed on the User Interface following a power-up
or system reset is listed below, complete with detailed descriptions of each
parameter. The unit of measurement (Metric or Imperial) for each signal is
selected from the Options code (MonitorCFG menu). The units are typically
congured at the factory as per customer requirements.
While in RUN Mode, the User Interface continually scrolls parameters. Each pa-
rameter can be paused momentarily on the User Interface based on the Scroll
parameter (MonitorCFG menu) setting (factory default is 4 seconds).
Upon power-up or a system reset, the User Interface will revert to the RUN
menu and begin scrolling the parameters. The rst parameter that will be seen
after a power-up or following a reset is the system’s rmware version (M241
Vx.xx).
RUN mode allows
you to view information
only. To change information
(ApplicCFG or MonitorCFG),
a password is required.
3-6 | 241CE II Hydrocarbon Dewpoint Analyzer
