PN 903-8797, Rev A
Analog Output Terminals
Typically, AMETEK provides two (2) self-powered analog outputs which do not
require a loop-power supply and are compatible with loop impedances of up
to 1000 ohms. Additional outputs can be included if specied by the customer
(for external Water Dewpoint or Water Content). The two (2) self-powered
analog outputs are used for Hydrocarbon Dewpoint (HCDP) Temperature and
Operational Status Code.
For self-powered and/or loop-powered analog output connection
locations, see Figure 2-3.
The standard analog output signals are discrete 420 mADC, 1500 Vrms iso-
lated current outputs congured as 2-wire transmitters (Figure 2-3).
The output ranges and measurement units (Figure 2-5) are the default factory
settings. The output ranges can be changed (except the Operational Status
Code – xed analog). For each output, the lower output range value (Figure
2-5) corresponds to 4.00 mA and the higher output range value corresponds to
20.00 mA.
However, when loop-powered V/Is are used, the customer must supply an
external loop-power supply (15–30 VDC) that is capable of supplying 25 mA
per loop.
Analog Input Signal
Terminal Default Output Range and Units
+ – Metric Imperial
* Water Dewpoint Temperature J101 2 J101 3 -40 °C to 40 °C -40 °F to 104 °F
Hydrocarbon Dewpoint Temperature J101 4 J101 5 -40 °C to 40 °C -40 °F to 104 °F
* Water Content J101 6 J101 7 0 to 1000 mg/m
3
(at 15 °C and
101.325 KPA)
0 to 62.43 lb/MMcf
(at 60 °F and
14.70 PSIA)
Operational Status Code J101 8 J101 9 0 to 255
0 to 13790 KPA
0 to 255
0 to 2000 PSIA
* Optional – Applicable if an external water signal is supplied and the H2O DP:EXT option is enabled from the
MonitorCFg menu.
** Optional – Applicable if an external water signal is supplied and the H2O CT:EXT option is enabled from the
MonitorCFg menu.
Figure 2-5.
Analog outputs, terminals,
default ranges, and units.
2-20 | 241CE II Hydrocarbon Dewpoint Analyzer
