PN 903-8797, Rev A
Spare Analyzer Fuses
AMETEK recommends having on-site spare fuses used in the analyzer. These
fuses do not need to be changed out at regular intervals, but are necessary in
the event that a fuse has blown and a replacement is required.
When ordering replacement fuses, note the dierent ratings and Part Numbers
for the ATEX and CSA Certied Units for the Solenoid fuse; all other fuses are
the same for both units. Recommended fuses include:
Description (Location * )
120 V 240 V
Part No. Fuse Type Part No. Fuse Type
Solenoid (F1)
ATEX:
(Fuse, Time Delay 5 x 20 mm CCC)
CSA:
(Fuse FST 250 V S/B 5 x 20 mm)
301-1278
300-9244
0.2 A
1.0 A
301-1277
300-9244
0.1 A
1.0 A
Logic Power Supply (F2)
(Fuse SPT 250 V CSA and VDE,
5 x 20 mm)
300-6254
2.0 A
300-6254
2.0 A
Cooler Power Supply (F3)
(Fuse SPT, 250 V CSA and VDE,
5 x 20 mm)
300-6256
6.3 A
300-6256
6.3 A
Fuses located on terminal strip (on Termination board) near the top of the Electronics Enclosure
(see Figure 4-4 for fuse ratings/locations).
Replacement Boards
If you require replacement boards for the 241CE II Analyzer, use the following
part numbers.
Printed Wiring Boards
Description (Location)
AMETEK
Part No.
Chapter/
Figure No.
Microcontroller Board (Door Housing, Electronics Enclosure) 100-1181 2-7
Termination Board (Electronics Enclosure) 100-1187 4-4
Optical Collar Flex Board (Detector (Measuring Cell) Assembly) 100-0665 4-1
Cooler Flex Board (Detector (Measuring Cell) Assembly)
Note:
* The Optical Cooler Flex Board is sold only as part of the
Opto-Ring Assembly, Part No. 100-2720.
100-0666 4-1
Non-Isolating I/V Daughter Board, optional
(Electronics Enclosure)
100-0650 —
Isolating I/V Daughter Board, optional (Electronics Enclosure) 100-0651 —
Maintenance and Troubleshooting | 4-5
