PN 903-8797, Rev A
Sub-Menu Item Description
I1H On the rst analog output – V/I #1 – this is the full-scale (maximum) WDP temperature
(°Cor°F) corresponding to the 20.00 mA output.
Note:
This parameter will be displayed only if an external water signal is provided and if
the H2O DP:EXT option is enabled from the MonitorCFG menu.
I2L On the second analog output – V/I #2 – this is the low-scale (minimum) HCDP temperature
(°Cor°F) corresponding to the 4.00 mA output.
I2H On the second analog output – V/I #2 – this is the full-scale (maximum) HCDP temperature
(°Cor°F) corresponding to the 20.00 mA output.
I3L On the third analog output – V/I #3 – this is the low-scale (minimum) WCT – mg/m
3
(lb/MMcf),
PPMV, or PPMW – corresponding to the 4.00 mA output.
Note:
This parameter will be displayed only if an external water signal is provided and if
the H2O CT:EXT option is enabled.
I3H On the third analog output – V/I #3 – this is the full-scale (maximum) WCT – mg/m
3
(lb/MMcf),
PPMV, or PPMW – corresponding to the 20.00 mA output.
Note:
This parameter will be displayed only if an external water signal is provided and if
the H2O CT:EXT option is enabled.
I4L The fourth analog output – V/I #4 – is reserved for the low-scale (minimum) pressure
(KPAorPSI) corresponding to the 4.00 mA output. This analog output is currently not used.
I4H The fourth analog output – V/I #4 – is the full-scale (maximum) pressure (KPA or PSI)
corresponding to the 20.00 mA output. This analog output is currently not used.
Chng PSCD1? This prompt asks if you wish to change Passcode1. To change the password for the ApplicCFG
menu, enter a new 4-character code, using any combination of the , ‘+’, and ‘–’ buttons. After
entering the password, “Chng PSCD1?” will be displayed again. Enter the passcode a second
time.
Save AppCFG? This prompt asks if you wish to permanently save the changes you made to the ApplicCFG
parameters. To save any changes you made, press the ‘+’ button. If the changes are not saved,
they will remain in eect until the analyzer is powered down or reset.
User Interface | 3-17
