Page #82 background image
PN 903-8797, Rev A
Sub-Menu Item Description
UsrRelay User-selectable relay type (Relay 4). Upon instructions from the customer, AMETEK can
congure Relay 4 (and LED 4) at the factory to indicate, when turned On, either:
NoD = Hydrocarbon Dewpoint Temperature Not Found.
If the User Relay is congured to indicate NoD, the condition is updated at the end of each
Cooling Stage. The result is used to interpret the temperature on the analog output signal
channels.
or
Pur = Purging/Hold Stage Is In Progress (typically used for Data Acquisition Systems (DAS)
or other remote systems).
If the User Relay is congured to indicate Pur, the relay will be activated at the beginning of
the Purging/Hold Stage and deactivated at the end of the Purging/Hold Stage. This function
indicates to remote DAS systems that new data is present on the analog output channels.
Note:
While this function is typically congured by AMETEK at the factory, the User
Relay can be changed from the ApplicCFG menu.
UsrVI User-selectable V/I type (Analog output 4). The only option currently available is:
SCode = basic Status Code [if H2O DP:DISAB option is enabled from the MonitorCFG
menu].
Net This parameter allows you to select the Network communications type. Options include:
S2K = System 2000 (Communicating via System 200 Congurator Software). For details
about using this software to communicate with the analyzer, refer to the 241CE II Analyzer
System 200 Congurator Software User Manual shipped with your system.
MODBUS = Communicating via Modbus.
For details about using Modbus interface to communicate with the analyzer, refer to the
241CE II Analyzer Serial Communication Interface (Modbus) Manual Supplement shipped
with your system.
MB Addr z Modbus slave address, used to select a port that will allow communications between a
computer and the analyzer, where ‘z is a number between 0–250. The denitions include:
Address Denition
0 Disable Modbus interface
1–127 Enable Modbus interface on RS-232 port
128–255 Enable Modbus interface on RS-422 port
Comm Serial communication type. Options include:
RS232 (system default)
• RS422
4WRS485 (4-wire RS-485)
2WRS485 (2-wire RS-485)
After selecting the desired serial communication type,
several jumpers on the CPU board may need to be changed in order to establish
communication. See jumper settings listed under “Conguring the Hardware for Digital
Communication in Chapter 2.
Baud Serial communication baud rate. Options include:
9600 (system default)
• 4800
• 2400
• 1200
I1L On the rst analog output – V/I #1 – this is the low-scale (minimum) WDP temperature
(°Cor°F) corresponding to the 4.00 mA output.
Note:
This parameter will be displayed only if an external water signal is provided and if
the H2O DP:EXT option is enabled from the MonitorCFG menu.
3-16 | 241CE II Hydrocarbon Dewpoint Analyzer
