PN 903-8797, Rev A
Displayed
Abbreviation Description
WMir The current phototransistor signal from the water side of the mirror (the
unit of light reected from the mirror surface).
During the analyzer’s rst Purge cycle (Purging/Hold Stage) after a power-
up, this value will be at its baseline level because there are no liquids on
the mirror.
HCMir The current phototransistor signal from the hydrocarbon side of the mirror
(the unit of light reected from the mirror surface).
During the analyzer’s rst Purge cycle (Purging/Hold Stage) after a power-
up, this value will be at its baseline level because there are no liquids on
the mirror.
The factory-set default conguration settings for your analyzer can be
found in the Documentation Package shipped with the analyzer.
3-8 | 241CE II Hydrocarbon Dewpoint Analyzer
