43AP 240
OPERATION MANUAL
Ignition box (1)
In ”0” position the Machine lighting will be connected along
with hand lamp socket. In ”I” position other consumers will be
connected. Spring-loaded position ”II” is used to start the en-
gine. Key can be removed in ”0” position only.
Note:
The key is identical to the key for locking the cabin door.
Travel controller (2)
It is used to adjust direction of running and for gear shifting via
a turning handle.
“F“ position - forward
“N“ position - idle (neutral)
“R“ position - backward
Horn pushbutton and fuse are part of the controller.
Position of “N“ fuse – controller interlocking.
2185
sta06
3397
0
I
3397
2582
2657
3003
2658
I
II
III
IV
0
2659
595200
2701
Ination valve (3), deation valve (4)
It is used to make up or deate tyre air.
For pressure values, please refer to the
Table in Section named Tyre Pressure
Control.
Do NOT switch ON both valves simulta-
neously to ”I” position!
Gearbox oil pressure gauge (5)
Operating oil medium pressure must move with-
in 12,5-15,5 bar range.
! CAUTION !
When pressure drops below 12,5 bar, stop the
Machine.
Gearbox oil temperature (6)
Operating temperature may move within 80 -
120 °C range. Max temperature is 120 °C.
Power view display (7)
Multifunctional instrument to display engine function and fuel
reading.
Brake circuit pressure gauge (8)
White indicator shows air pressure inside air res-
ervoir - adjusted to max 8 bar.
Red one indicates air pressure when braking - air
pressure from air brake valve to brake booster.
Tire pressure gauge (9)
The minimum air pressure after air release from
tyres has been adjusted to 1,5-2 bars.
TOTAL STOP (10)
Press to stop the Machine and its engine instant-
ly in emergency event.
Indication of workplace enabled (11)
Indicates from which position (seat) the Roller travel is con-
•
trolled.
If no indicator lamp (11) ashes with the ignition box key
•
turned ON then the engine can be started. If indicator lamps
(11) ash with the ignition key turned ON, then the engine
cannot be started since one or two travel controllers are not
in N position - idle indicator lamp does not light.
Sprinkling interval control (12)
Turn the switch left to start up the pump to run
continuously - tires will be sprinkled constantly.
Turn the switch to any of four positions in clock-
wise direction to turn ON sprinkling interval con-
trol.
Position I sprinkling for 10 s dwell for 10 s
Position II sprinkling for 10 s dwell for 15 s
Position III sprinkling for 10 s dwell for 22 s
Position IV sprinkling for 10 s dwell for 33 s
Sprinkling indicator lamp will light only when
pump is running.
Socket (13) - to connect to ECM (Electronic
Control Module) designed to diagnose any
defects or to adjust engine parameters.
Trimmer (14) - downward, upward - optional
Direction-indicator lights (15)
