2.2.3 Voltage Overload on Input2 Connector
CAUTION
The Input2 connector has a built-in a voltage overload protection circuit for
protecting circuits should you accidentally apply to much power. The maxi-
mum value is 10 Vrms when impedance 1 MΩ is selected and 2 Vrms when 50 Ω
is selected. Do not input voltage higher than those values. Failing to obey this
warning may cause internal circuits to burn out.
Fig. 2-3 Input2 Connector
