2-5
2.2.4 Voltage Overload on Reference 1, 2, 5, and 10 MHz Input Connec-
tor
CAUTION
The input level for the reference 1, 2, 5, and 10 MHz Input connector is 1 to 5 Vp-
p. Applying a voltage exceeding 7 Vp-p may cause internal circuits to burn out.
Fig. 2-4 Reference 1, 2, 5, and 10 MHz Input Connector
2.2 Safety Measures
