Anviz P7 User Manual

User Manual
10
 Support Low-frequency card : EM Card and other compatible card(125kHz)
 Support TCP/IP, RS485, Mini USB Slave, Wiegand Out & In
 Can be connected with the SC011 access controller system to achieve split security
 Registration capacity: 3000 Fingerprints and 50000 Records
2.3 Technical Parameters
Item
Description
Comparison Time
<0.5 sec
Recognition Mode
Fingerprint, Password, Card
The area for the
fingerprint collection
22mm*18mm
Image Resolution
500DPI
FRR
0.001%
FAR
0.00001%
Standard Interface
RS485, TCP/IP, Mini USB Slave, Wiegand Input
and Output
Operating Voltage
DC12V
Relay
Relay Output (COM, NO, NC or Direct Lock
Control)
POE
Nominal Power less than 13W
Operating
Temperature/ Humidity
-25℃-70℃ / 0％-90％
Material
ABS Engineering Plastics
Size
54(W)×170(H) ×41(D)mm
Color
Black

Anviz P7 Specifications

General

Brand	Anviz
Model	P7
Category	IP Access Controllers
Language	English
