ARAG Skipper LT - Treatment Status Signal; Connection to the Power Source

11
5.9 Treatmentstatussignal
If the machine is equipped with a treatment control, such as a switch on the control valve, the SKIPPER LT can be connected to a corresponding
treatment status signal, so that it receives a +12 Vdc signal directly from the control itself when treatment starts.
We recommend that the control be connected to the main control valve positive pole.
Since the current in question is very low, the cable connection to the control need not be of any special cross-section.
CAUTION:theconnectiontothetreatmentcontrolmustbedonebyaqualiedtechnician.
ARAGisnotliablefordamagetothesystem,persons,animalsorthingsduetoincorrectconnectionoftheabovecontrolor
modicationstothesystem,cabling,connectorsoranyothercomponentsrequiredtomaketheconnection.
• If the treatment start control connection is not made, the operational status of the equipment must be entered into the SKIPPER LT manually with
the key USER.
5.10 Connectiontothepowersource
WARNING!
Toavoidshortcircuits,donotconnectthepowercablestobatterybeforetheinstallationiscompleted.
Beforepoweringupthesatellitenavigator,makesurethetractorbatteryvoltageratingiscorrect(12Vdc).
Skipper LT is directly powered by the farming machine battery (12 Vdc): ALWAYS switch satellite navigator on through the relevant procedure; after
use, remember to manually switch Skipper LT off through the relevant push-button on control panel.
LeavingSkipperLTonfortoolongwhilefarmingmachineisstoppedcoulddrainthetractor'sbattery.Ifthemachinestayswith
engineoffforalongtime,makesureyoudisconnectSkipperLTfromthebattery(Fig.10).
WARNING:
•ThepowercircuitmustALWAYSbettedwitha3Ampautomotivefuse.
•Allcablesconnectedtothebatteryshallhaveaminimumcross-sectionof1sq.mm.
•Usecableswithsuitableterminalsensuringcorrectconnectionofallwires.
INSTALLATION
