ARAG Skipper LT - F4 Align

41
8.2.4
F4Align
Shift the closest reference track and realign it to machine position
Press
F4 if you need to realign, maintaining the same direction (such as with maize, sugar cane).
- Set to the position you would like to set as new reference track and press F4.
- The "old" reference track F (Fig. 120) shifts and aligns to tractor centre: all other reference tracks shift accordingly.
- The "old" deviation value >4.2< (G) becomes >0.0< because it takes the "new" track as reference.
Fig. 120
Afterusingthe"Align"function,itisnotpossibletorecovertheinitialreferencetrack.
WORK FUNCTIONS - PAGE 2
