ARAG Skipper LT - Locating the Antenna

8
5.6 Locatingtheantenna
TheusermustpositiontheGPSantennaasindicatedinthismanualandmakesurethatthemodiedvehicleheightdoesnot
leadtoanimpactwithanyobstacle.
Installing the antenna:
Installation of the antenna on agricultural equipment must observe certain basic requirements:
• it must be installed on the highest point of the machine (including trailer): the skywards reception angle must be as unobstructed as possible.
Fig. 5
Fig. 6
The antenna must be installed on the lengthwise axis of the machine.
Fig. 7 Fig. 8
INSTALLATION
