Array electronic SH-300 User Manual

SH-300 Text Panel
Page 100 of 103
UP/DOWN
Counter
UDCT
The number of the
corresponding
function block in SR
program: (0~127)
Read/Write
Select “Property Parameter”
to set count value for
function block.
analog comparator
CMPR
The number of the
corresponding
function block in SR
program: (0~127)
Read/Write
Select “Property Parameter”
to set comparison value for
function block.
Input analog IN
0~7
Read
Read analog input value
Garph
bar
ON Delay TOND
The number of the
corresponding
function block in SR
program: (0~127)
Read(*2)
Display the current value of
function block.
OFF Delay TOFD
The number of the
corresponding
function block in SR
program: (0~127)
Read(*2)
Display the current value of
function block.
Single pulse
generator PONS
The number of the
corresponding
function block in SR
program: (0~127)
Read(*2)
Display the current value of
function block.
Clock pulse
generator BLNK
The number of the
corresponding
function block in SR
program: (0~127)
Read(*2)
Display the current value of
function block.
Holding-ON-delay
relay MTOD
The number of the
corresponding
function block in SR
program: (0~127)
Read(*2)
Display the current value of
function block.
UP/DOWN
Counter
UDCT
The number of the
corresponding
function block in SR
program: (0~127)
Read(*2)
Display the current value of
function block.
analog comparator
CMPR
The number of the
corresponding
function block in SR
program: (0~127)
Read(*2)
Display the current value of
function block.
Input analog IN
0~7
Read(*2)
Dsplay analog input value
Dynamic
text
UP/DOWN
Counter UDCT
The number of the
corresponding
function block in SR
program: (0~127)
Read
Display the dynamic text
corresponding to count
value.
Note: *1 The text panel displays the time in the format of hour: minute: second-millisecond. If
the displayed time exceeds 1 hour, the millisecond will not be displayed.
*2 when the current value of TOND TOFD PONS BLNK MTOD function block is
displayed by graph bar ,the min and max limit of register = the current value *100
when the analog input value is displayed by graph bar ,the min and max limit of
register = the analog value *10
