4.15 KDN-K3 Series
SH-300 can communicate with KDN-K3 series PLC, the communication port is the programming
port of PLC
SH-300 software configuration:
Item
Content
SH-300 COM port
9 pin COM port
PLC COM port
Programming port
Default parameter
9600bps、8bits、1stop、None
Station No.
1－31，1 is Windows default
Distance (Max.)
15m
Communication mode
RS232
Cable type
Special cable
Inner relay address
I0.0-I7.7/ Q0.0-Q7.7/ M0.0-M31.7
Register address
AIW0-62/AQW0-62/AQW0-4094
Connection guidance of Special cable:
SH-300 side
2 RXD
2 RXD
PLC side
9 pin D shape
3 TXD
3 TXD
9 pin D shape
Female plug
Male plug
5 GND
5 GND
( when SH-300 communicates with KDN-K3 series PLC you are recommended to use the
programming cable )
