SH-300 User’s Manual Connection with PLC
Page 67 of 103
4.3 OMRON C Series
SH-300 can communicate with the programming port of CQM、CPM series PLC through
HOST-Link protocol.
SH-300 software configuration:
Item
Content
SH-300 COM port
9 pin COM port
PLC COM port
Programming port/ external communication port
Default parameter
9600bps、7bits、2stop、Even
Station No.
0-99 ,0 is Windows default
Distance (Max.)
15m
Communication mode
RS232
Cable type
Special cable
Inner relay address
IR200.0-IR231.F(IR2000.0-IR231.15)
Register address
DM000-DM1024
Note: Because CQM-CPU11 and CAPM1A have only one COM port. you must use the
programming cable or the CIF01-CAB Communication module of the OMRON
communicating with SH300
Connection guidance of Special cable
SH-300 side
2 RXD
2 TXD
PLC side
9 pin D shape
3 TXD
3 RXD
9 pin D shape
Female plug
5 GND
9 GND
male plug
Note: the register won’t be set unless the CPU must work in the monitor mode
