SH-300 User’s Manual Software Part
Page 39 of 103
When SH-300 is working normally, if there is any failure alarm or M0 and M2 are ON, the flashing
alarm screen will prompt automatically on SH-300 as in the following:
If the alarm failure is not corrected, the failure alarm information will flash and be displayed on
SH-300. If the failure is corrected, the SH-300 will resume normal display. If the system is in
examination and repair, user can check the failure alarm records via the “ALM” key on the panel.
After the checking, press “ESC” key to return to the main interface.
2.6 User-defined SH300 system information
SH300 provides completely open system information menu structure, which provides user with
completely self-defined menu. You can use any language system to edit your information menu
and at the same time the coordinate position of the menu can be relatively changed according to
your demand.
After standard installation of SH300 software, the default information menu will be loaded
automatically when downloading data. The menu option lies in the submenu “Immanent
resource” of the menu “Tool”.
Click “Immanent resource“, then the following diagram will be shown:
