SH-300
User’s Manual Hardware Part
Page 9 of 103
1.4 Function Key List
When modifying the register data, the cursor will be moved one-digit left.
When modifying the register data, the cursor will be moved one-digit right.
To jump to the previous screen, whose number is set in the screen property option.
(The default value is the current number 1.)
In data-setting mode, pressing it, the modified number will be plus 1. The incremental
range is 0 to 9 (in decimal system) and 0 to F (in hexadecimal system).
To jump to the next screen, whose number is set in the screen property option. (The
default value is the current number plus 1.)
In data-setting mode, pressing it, the modified number will be minus 1. The incremental
range is 9 to 0 (in decimal system) and F to 0 (in hexadecimal system).
In data-setting mode, sign of the modified number will be set.
In data-setting mode, the modified number will be set as the corresponding number.
Exit from the current operation such as register set, password input, alarm display and
so on.
Pressing this key, you can enter the system-defined alarm information screen.
Pressing this key, you can modify the register data. The current modified register will
be color-reversely displayed and the current modified digital will be flashing. If there is
no register set component in current screen, the operation is the non-operation. If
press SET key again before pressing ENT, the current operation will be canceled and
you can continue to modify the next register data
In the situation that the password protected function is used, pressing this key, the
password set screen will be displayed.
In register-setting mode, pressing this key the modified data will be written into the
register and then it will continue to modify the next register data.
When the last register in this screen is modified, pressing this key, it will exit the
register modification state.
In data-setting mode, clear the set data.
