Array electronic SH-300 User Manual

SH-300 Text Panel
Page 96 of 103
14
Reserved byte
00
Coil status [data N]
01
15
Reserved byte
00
Verify value
04
16
Verify value
FC
4.18 Array FAB Series PLC
SH-300 can communicate with Array FAB series PLC, and the communication port is the
programming port of PLC.
SH-300 software configuration:
Item
Content
SH-300 COM port
9 pin COM port
PLC COM port
Programming port
Default parameter
9600bps、8bits、1stop、none
Station No.
0-254, default value: 0
Distance (Max.)
15m
Communication mode
RS232
Cable type
AF-C232/AF-D232
Explanation: The station number of SH-300 must be the same one as the current address value
in FAB communication configuration, or the SH-300 can not communicate with FAB normally.
The description of address types used in SH300 software:
Example 1: As the following FAB program shows, SH-300 can display the status of I1~I6, Q1~Q4,
and can control the ON/OFF status of Q2, Q3, Q4 through the function key, and can
Object
type
Address
type
Address range
Read/
Write
Description
Indicator
I
1~12
Read
Read input status
Q
1~8
Read
Read output status
M
The number of the
corresponding auxiliary relays
in FAB program: (0~127)
Read
Read the output status of the
function block in FAB program.
Function
key
Q
1~8
Write
Write the status of empty output
port (the output port that is not
programmed in FAB program.)
Dynamic
text
I
1~12
Read
Read input analog value (DC
type PLC)
B
The number of the
corresponding function block in
SR program: (0~127)
Read
Read the parameter value of the
function block in FAB program.
Register
I
1~12
Read
Read input analog value
B
The number of the
corresponding function block in
SR program: (0~127)
Read
Read the parameter value of the
function block in FAB program.
Write
Read the parameter value of the
function block in FAB program.
B
The number of the
corresponding function block in
SR program
Read
Read the parameter value of the
function block in FAB program.
