ASCOM UPAC Series User Manual

TD 92483GB
2008-06-05/ Ver. B
Installation and Operation Manual
UPAC- Unite Packet for Messaging and Alarm
34
5.1.2 Ascom Line Protocol
1 The following settings can be selected/changed:
2 Click “Activate”.
Settings Description
Enabled: Yes/No selection. Default: No
Name: Description of the channel
Serial port: Port selection (1,2,3)
Default: None
Port 3 will be selected when set from the Wizard,
but all three ports can be configured here. Note
that only one at the time can be used.
Bit rate: Select bit rate.
Default: 9600 bits/s
Mode: Select mode.
Default: 8 Data bits, Even parity
Flow control: Used for handshaking control. Default: None
Default Call ID: Number to call if not specified in the external
equipment. Default: 000
Default display message: Message to display if not specified in the external
equipment. Default: BLANK
Default message priority: Priority if not specified in the external equipment.
Default: 7 (Normal)
Default beep code: Beep code if not specified in the external
equipment.
Default: 2 beeps
Transmission delay (x10 ms): How long to wait before transmission to external
equipment. Default: 30 milliseconds
Status to ext equipment: If status characters ACK/NAK shall be sent on
protocol level to external equipment.
Default: Yes
Start character : Start character for the message.
Default: < (3C Hex)
End character: End character for the message.
Default: > (3E Hex)
Record separator character: Record separator character for the message.
Default: / (2F Hex)
ACK character: Character for positive acknowledge of the message
on protocol level. Default: A (41 Hex)
NAK character: Character for negative acknowledge of the
message on protocol level. Default: N (4E Hex)
ASCII conversion table: Makes it possible to convert display message
characters.
