TD 92483GB
2008-06-05/ Ver. B
Installation and Operation Manual
UPAC- Unite Packet for Messaging and Alarm
36
• Open ports
1 Click “Edit” for Open Ports in the Remote Management Server page, to open any
additional ports that are needed for configuration tools. To be able to configure
ports, section 8 on switch number 3 has to be set to ON.
For WinBK, CSM and TIP port 10101 has to be open. To be able to use the Activity
Log Viewer over a remote connection, port 10130 has to be open.
2 Set up the port parameters and click “Activate”.
• Serial port channel
1 Click one of the “NOT USED” links for Serial port channel in the Remote
Management Server page, to set up a new channel.
One serial port channel for each tool, for example WinBK for System 900
configuration, has to be set up. Web based configuration tools do not require serial
port channels.
2 Set up the channel and click “Activate”.
The configuration of the remote management server is described in detail in Function
Description, Remote Management, TD 92257GB.
Figure 53.
Figure 54.
