Aspen Avionics EFD1000 - Introduction; Part Numbers; Authorized Configurations

EFD1000 Installation Manual
DOCUMENT # A-01-126-00 PAGE 11-225 Revision H
© Copyright 2009 Aspen Avionics Inc.
1 Introduction
This Installation Manual is FAA Approved and contains detailed installation instructions for
installing the EFD1000 System into specific aircraft as listed in the EFD1000 AML-STC. There are
required FARs that must be complied with and followed to insure an airworthy installation. Section
5 Pre Modification Planning will guide you through these requirements.
1.1 Part Numbers
List of the major components (by part number) that make up the EFD1000 system complying
with the standards prescribed in this TSO.
• A-05-110-00 EFD1000 (PFD)
• A-05-111-00 REMOTE SENSOR MODULE (RSM)
• A-05-112-00 ANALOG CONVERTER UNIT (ACU) – optional
• A-05-113-00 CONFIGURATION MODULE, PFD PILOT
OR
• A-05-114-00 CONFIGURATION MODULE, PFD PRO
OR
• A-05-118-00 CONFIGURATION MODULE, PFD PRO DIGITAL
• A-08-130-00 INSTALLATION KIT, EFD1000
• A-08-131-00 INSTALLATION KIT, RSM
• A-08-132-00 INSTALLATION KIT, ACU – optional
1.1.1 Authorized Configurations
The following table identifies the authorized system configurations
System ACU Configuration Module RSM
EFD1000 Pro Optional* CONFIGURATION MODULE, PRO Required
EFD1000 Pro Digital None CONFIGURATION MODULE, PRO DIGITAL Required
EFD1000 Pilot None CONFIGURATION MODULE, PILOT Required
* ACU Software Version A-02-178-1.1 or subsequent is required for the G-550A or the
52C77 Flight Director emulation. The software version is marked on the ACU.
