6.11 Configuration Module Installation
The Configuration Module will be cable tied to the PFD wire harness. Leave just enough slack
in the cable ties so that the configuration module can slide along the PFD cable. This will
prevent strain on the configuration module connector while the PFD harness is manipulated
during installation and subsequent removal/replacement.
Figure 6.19 – Configuration Module Dimensions (inches)
Cable Tie two (2) places
Figure 6.20 – Configuration Module Tie Wrapped to Harness
