EFD1000 Installation Manual
DOCUMENT # A-01-126-00 PAGE 196-225 Revision H
© Copyright 2009 Aspen Avionics Inc.
13 Environmental Qualification Forms
Nomenclature: EFD1000 Primary Flight Display (PFD)
Part Number: A-05-110-00
TSO Numbers: TSO-C2d, TSO-C3d, TSO-C4c, TSO-C6d, TSO-C8d, TSO-C10b,
TSO-C106, TSO–C113
Manufacturer: Aspen Avionics, Inc
Address: 5001 Indian School Road NE, Albuquerque, NM 87110
DO-160 Revision: DO-160E
Date Tested: 2/2008
CONDITIONS SECTION DESCRIPTION OF TESTS CONDUCTED
Temperature and Altitude
(Pressurized)
4.0 Equipment tested to Category A1, Decompress to 55,000”, Controlled temp
and pressurized to <15,000’
Temperature and Altitude
(Unpressurized)
4.0 Equipment tested to Category C1, Controlled temp and non-pressurized to
35,000’
Loss of Cooling 4.5.5 Equipment tested to Category Y, 300 minutes min.
Temperature Variation 5.0 Equipment tested to Category C
Humidity 6.0 Equipment tested to Category A, standard humidity environment
Operational Shock and
Crash Safety
7.0 Equipment tested to Category B, standard operational shock and crash safety
Vibration (Fixed Wing) 8.0 Equipment tested to Category S, aircraft Zone 2 for Fixed Wing Reciprocating &
Turboprop Engines, Multi Eng over 5700 KG (12,500 lbs), Multi Eng Less than
5700 KG (12,500 lbs), and Single Eng Less than 5700 KG (12,500 lbs) using
vibration test curve M.
Explosive Atmosphere 9.0 Equipment identified as Category X, no test performed
Waterproofness 10.0 Equipment identified as Category X, no test performed
Fluids Susceptibility 11.0 Equipment identified as Category X, no test performed
Sand and Dust 12.0 Equipment identified as Category X, no test performed
Fungus 13.0 Equipment identified as Category X, no test performed
Salt Fog Test 14.0 Equipment identified as Category X, no test performed
Magnetic Effect 15.0 Equipment tested to Category Z, causes < 0.5 deg deflection to compass 0.3
meter away
Power Input 16.0 Equipment tested to Category B
Voltage Spike 17.0 Equipment tested to Category A
Audio Freq Conducted
Susceptibility
18.0 Equipment tested to Category B
Induced Signal
Susceptibility
19.0 Equipment tested to Category ZC
RF Susceptibility 20.0 Equipment tested for conducted susceptibility to Category W and for radiated
susceptibility Category W. Bench test to show compliance with interim HIRF
rules. 100V/m
RF Emissions 21.0 Equipment tested to Category M, significant EM apertures, not in direct view of
radio receiver antenna (Equipment mounted in cockpit or cabin area)
Lighting Induced Transient 22.0 Equipment tested to Category B3K33, moderately exposed all-metal airframes,
airframes composed of metal framework and all composite skin panels or carbon
fiber composite airframes whose major surface areas have been protected with
metal meshes or foils
Lightning Direct Effects 23.0 Equipment identified as Category X, no test performed
