EFD1000 Installation Manual
DOCUMENT # A-01-126-00 PAGE 40-225 Revision H
© Copyright 2009 Aspen Avionics Inc.
The autopilot’s flight director output may be paralleled from the autopilot to the
existing Flight Director and ACU so that it is displayed on both instruments. The FD
may also be connected to just the ACU for Flight Director display on the PFD when
there is no existing flight director.
5.6.2 GPS Navigator Basemap Compatibility
Not all GPS navigator outputs are the same. Some navigators provide output to
support curved flight plan segments. Other navigators can only provide the straight
segments of a flight plan, and the curved segments are not depicted. Some navigators
provide an output that results in a straight-line depiction of a curved flight plan
segment, which should not be used. It is possible to connect the navigator in an
incorrect configuration, resulting in potentially misleading information to the pilot.
The following table identifies the correct configuration of compatible systems:
Navigator Navigator Mode
and/or
Type of Connection
EFD1000 Mode
and/or
Type of Connection
Basemap Depiction
Apollo
GX50
GX60
GX65
Standard Mode, RS-
232
Normal Mode, RS-
232
This connection method presents straight-
leg portions of flight plans. An open
segment is shown in lieu of a curved
segment.
Bendix King
KLN 90/A/B,
KLN900
Standard Mode, RS-
232
Normal Mode, RS-
232
This connection method presents straight-
leg portions of flight plans. An open
segment is shown in lieu of a curved
segment.
KLN 90B ARINC 429 This configuration
should not be used.
This connection method can incorrectly
display the map information.
Bendix King
KLN 94
KLN 89/B
Standard Mode, RS-
232
Normal Mode, RS-
232
This connection method presents straight-
leg portions of flight plans. An open
segment is shown in lieu of a curved
segment.
Bendix King
KLN 94
“Enhanced
Mode”
Enhanced Mode,
RS-232
This configuration
should not be used
This connection method can incorrectly
display curved segments as straight lines
and the displayed information can be
misleading to the pilot in certain
conditions.
Garmin
GPS155
GPS155XL
GPS300XL
GPS165
GNC300
ARINC 429 ARINC 429 This connection method presents curved
approaches.
Garmin GNS-400
Series
ARINC 429 ARINC 429 This connection method presents curved
approaches.
