Aspen Avionics EFD1000 - Installation Kit Contents

EFD1000 Installation Manual
DOCUMENT # A-01-126-00 PAGE 12-225 Revision H
© Copyright 2009 Aspen Avionics Inc.
1.2 Installation Kit Contents
A-08-130-00 EFD1000 Install Kit
Aspen P/N Description Manufacturers P/N
A-08-125-00-A PFD Mounting Bracket Aspen
A-06-564-00 44 Pin HD D-Sub connector with
contacts
Positronics P/N DD44F10000
A-06-573-00 EMI Metal Back shell Positronics P/N D25000GE0
A-06-507-00 Pitot Quick Connector Aspen
A-06-505-00 Static Quick Connector Aspen
A-08-144-00-A Configuration Module Connector
Assembly with pigtail
Aspen
A-08-131-00 RSM Install Kit
Aspen P/N Description Manufacturers P/N
A-08-148-00-A
RSM 30ft cable assembly w/connector
(optional)
Aspen
201-00004-001
Screw, Machined, Pan, Phillips, Brass, 8-
32 1¼”
MS35214-47
212-00001-001
Nut, Hex, Locking, Nylon Insert, Brass 8-
32
MS21044B08
231-00001-001
Washer, Flat, #8, Brass, Plain, 11/64” ID,
3/8 OD, NAS1149B0832H
NAS1149B0832H
256-00001-001 O-Ring AS568A-120
116-00020-001
Connector, Threaded Plug, In-Line, Male,
7 Pin
N/A
A-08-132-00 ACU Install Kit
Aspen P/N Description Manufacturers P/N
A-06-570-00 15 pin D-Sub connector AMP P/N 205163-1
A-06-571-00 25 pin D-Sub connector AMP P/N 205165-1
A-06-572-00 37 pin D-Sub connector AMP P/N 205167-1
A-06-408-00 DB15 pin EMI Back shell NorComp 970-015-030R121
A-06-409-00 DB25 EMI Back shell NorComp 970-025-030R121
A-06-410-00 DB37 EMI Back shell NorComp 970-037-030R121
A-06-574-00 Crimp Sockets (77) Positronics P/N FC6020D
