Aspen Avionics EFD1000 User Manual (English)

Other manuals for Aspen Avionics EFD1000

Instructions For Continued Airworthiness36 pages

Airplane Flight Manual Supplement29 pages

Questions and Answers:

M
Morgan MoralesAug 1, 2025
How to troubleshoot Aspen Avionics Autopilot System display that does not power on?
- K
  Kayla OdonnellAug 2, 2025
  If the display doesn't power on, there could be several reasons: 1. The PFD might be missing A/C power. Check the PFD circuit breaker, the PFD on/off switch on the panel, the wiring, and ensure the A/C battery voltage is above 11.5 volts. 2. The PFD might have been improperly shut down. Try switching the unit off using the “REV” button or the “SHUT DOWN” command. 3. The PFD might be missing A/C ground. Inspect the wiring to the PFD. 4. The PFD itself might be defective, requiring repair or replacement.
J
Joshua KingAug 6, 2025
What to do if Aspen Avionics Autopilot System display does not power off?
- M
  Melissa HicksAug 6, 2025
  If the display doesn't power off, consider these possibilities: 1. If the airspeed is above 30 knots, this is normal operation. 2. The PFD may have been switched to internal battery. Switch the unit off using the “REV” button or the “SHUT DOWN” command. 3. The PFD may have been improperly shut down. Hold the “REV” button for 20 seconds or unplug the PFD internal battery for 3 seconds. 4. The PFD might be defective, and require repair or replacement.
W
wallacestephanieAug 10, 2025
How to fix “CONFIG MODULE LINK FAIL” message on Aspen Avionics EFD1000 Autopilot System?
- S
  smorrisAug 10, 2025
  If you're seeing a “CONFIG MODULE LINK FAIL” message, it could be due to: * The Configuration Module being unplugged or miss wired. Check the CM plug and wiring from the PFD to the CM. * A defective Configuration Module. In this case, repair or replace the CM. * A defective PFD. In this case, repair or replace the PFD.
S
Sarah MerrittAug 14, 2025
What does “RSM LINK FAIL” mean on Aspen Avionics EFD1000 Autopilot System and how to resolve it?
- S
  sheltonrobertAug 14, 2025
  An “RSM LINK FAIL” message indicates a communication problem between the RSM and the PFD. Possible causes include: * Lost communication between the RSM and PFD. Check the RSM to PFD wiring for shorts or opens. * A failed RSM. Consider repairing or replacing the RSM. * A failed PFD. Consider repairing or replacing the PFD.
R
Ryan WilsonAug 18, 2025
Why is my Aspen Avionics EFD1000 display flashing on/off?
- D
  deanshaneAug 18, 2025
  If the display is flashing on/off, showing black/white or blue/white repetitively, the cause may be: * The Configuration Module is unplugged or miss wired. Check the CM plug and wiring from the PFD to the CM. * An RSM or CM wiring short. Verify RSM pin 6 or CM pin 1 is not shorted to aircraft ground or another pin. * A defective Configuration module. Repair or replace the CM. * A defective PFD. Repair or replace the PFD.
M
michaeljohnsonAug 22, 2025
Why does my Aspen Avionics EFD1000 Autopilot System show “INITIALIZING” message for too long?
- T
  Theresa AndersonAug 23, 2025
  If the system displays the “INITIALIZING” message for more than 30 seconds, this may be caused by: * A loss of communication between the RSM and PFD. Check the RSM to PFD wiring for shorts or opens. * A failed RSM. Repair or replace the RSM. * A failed PFD. Repair or replace the PFD.
A
Audrey WrightAug 27, 2025
What does “WRONG CONFIG MODULE” message mean on Aspen Avionics EFD1000 Autopilot System?
- A
  aliciamccarthyAug 27, 2025
  The “WRONG CONFIG MODULE” message indicates that the PFD and the configuration module are at different software levels. To resolve this, convert the configuration module per the appropriate service bulletin.

Aspen Avionics EFD1000 Specifications

General

Brand	Aspen Avionics
Model	EFD1000
Category	Autopilot System
Language	English

Summary

Special Notes to the Installer

Document Revisions

Introduction

Part Numbers

Lists major components by part number for the EFD1000 system.

Authorized Configurations

Identifies the authorized system configurations for the EFD1000.

Installation Kit Contents

Accessories Required but Not Supplied

Lists required accessories not included in the kit.

Optional Accessories Not Supplied

Lists optional accessories available for purchase.

Special Tools Required

Lists specialized tools for installation.

Vendor Information

Contact details for component vendors.

Warranty Registration

Instructions for warranty registration.

Regulatory Compliance

Details compliance with TSO, Software, and Environmental standards.

Equipment Specifications and Limitations

Primary Flight Display (PFD) & Configuration Module (CM)

PFD and CM specifications.

Remote Sensor Unit (RSM)

RSM specifications.

Analog Converter Unit (ACU)

ACU specifications.

System Description

Primary Flight Display (PFD)

PFD description and features.

Remote Sensor Module (RSM)

RSM description and components.

Configuration Module

Configuration module function.

Analog Converter Unit (ACU)

ACU function and compatibility.

System Architecture

Diagram of system interconnections.

Supported Installed Configurations

Pilot Configurations

Basic Pilot installation options.

Pro Digital Configuration

Pro Digital installation configuration.

Pro Configurations with Autopilot

Pro installations with autopilot.

Pro Configuration with Autopilot and Digital/Analog VLOC

Pro config with AP, Digital/Analog VLOC.

Pro Configuration with Autopilot and Dual Analog VLOC

Pro config with AP and Dual Analog VLOC.

Pre Modification Planning

Pre Modification Checklist

Checklist for aircraft suitability for installation.

Requirements and Limitations

FAR requirements for secondary instruments.

Standby Attitude Positioning

FAR requirements for attitude indicator placement.

Standby Airspeed and Altimeter Positioning

Requirements for airspeed/altimeter placement.

Directional Gyro/ HSI

EFD1000 replacing DG/HSI.

Back Up Nav Indicator

Requirement for backup navigation indicator.

Aircraft Power Requirements

Electrical load analysis and capacity.

EFD1000 Power Requirements

PFD power requirements and switches.

Special Considerations for Aircraft Limited to VFR

FAA policy on secondary attitude indicators for VFR.

Optional Interfaces

Options for autopilot and navigation interfaces.

Autopilot

Autopilot compatibility and emulation.

GPS Navigator Basemap Compatibility

Compatible GPS systems for basemap.

GPSS

GPS Steering (GPSS) functionality.

GPS/ NAV Switching

PFD handling of GPS/NAV switching.

Heading Output

Heading data output to external devices.

Flush or Recess Mounting the PFD

PFD mounting options.

Mechanical Installation

Unpacking and Inspecting Equipment

Unpacking and inspection procedures.

Equipment Location Documentation

Documenting LRU locations and wire routing.

Weight and Balance

Weight and balance calculation guidance.

Installation Limitations

PFD and RSM mounting limitations.

Equipment Bonding

Bonding requirements for components.

Cooling

Cooling requirements for the PFD.

PFD Installation

Connecting the Internal Battery

PFD internal battery connection steps.

PFD Mounting Location

PFD mounting location requirements.

Mounting Bracket Installation

PFD mounting bracket installation.

PFD Bonding Strap

PFD bonding strap installation.

RSM Installation

Proposed RSM Location Check

Checking RSM location for magnetic interference.

Pressurized Aircraft

RSM wiring penetration on pressurized aircraft.

RSM mounting on Composite or Fabric

Approval for composite/fabric mounting.

RSM Mounting Angles

Maximum RSM mounting angles.

RSM Doubler

Use of doubler for aluminum-skinned aircraft.

RSM Doubler Fabrication

Fabrication details for RSM doubler.

RSM Installation

RSM mounting procedure.

RSM Shim Fabrication (if necessary)

Fabrication of RSM shims.

ACU Installation

ACU Mounting

ACU mounting instructions.

Configuration Module Installation

Electrical Installation

Electrical Load Analysis

Verifying compliance with FAR 23.1351(a).

Electrical Installation

Wiring and circuit breaker installation.

HIRF/Lightning Requirements

Cable requirements for HIRF/Lightning compliance.

PFD to GPS/VLOC/ACU Wiring

Wiring to PFD from GPS, VLOC, ACU.

RSM Wiring

PFD to RSM wiring instructions.

Configuration Module Wiring

Configuration module wiring.

ACU Wiring

ACU wiring instructions.

Autopilot Wiring

Autopilot wiring to ACU.

Electrical Connections

PFD Electrical Specifications

PFD power, tone, and RS-232 input specs.

ARINC 429 GPS Inputs

ARINC 429 GPS input labels and parameters.

ARINC 429 VLOC Input

ARINC 429 VLOC input labels.

ARINC 429 GPS Output

ARINC 429 GPS output labels.

ACU Electrical Specifications

ACU electrical specifications.

VLOC Receiver

VLOC receiver input specifications.

GPS Receiver

GPS receiver OBS specifications.

Autopilot

Autopilot interface specifications.

PFD Pin Out

RSM Pin Out

Configuration Module Pin Out

ACU Pin Out

Installation Wiring Diagrams

Configuration and Equipment Checkout

Test Equipment

Required test equipment for checkout.

Wiring Verification

Steps for wiring verification.

Bonding Check – FAR 23.867(b)

Bonding resistance checks.

System Configuration

Main Menu Access

Accessing the Main Menu.

Menu Navigation

Navigating menus.

Edit Mode

Modifying editable fields.

Main Menu Configuration

Overview of Main Menu settings.

INSTALLATION MENU – UNIT CONFIGURATION

Accessing the Installation Menu.

INSTALLATION MENU PAGE 1 - IAS CONFIG A

IAS speed band configuration.

INSTALLATION MENU PAGE 2 – IAS CONFIG B

IAS speed marker configuration.

INSTALLATION MENU PAGE 3- IAS CONFIG C

IAS units, TAPES, VSPD EDIT config.

INSTALLATION MENU PAGE 4 – MISC CONFIG

RSM GPS, Elec Sys, Attitude Trim config.

INSTALLATION MENU PAGE 5 – NAV SET UP

GPS/NAV/Autopilot interface config.

INSTALLATION MENU PAGE 6 – A429 CONFIG

A429 config status pages.

INSTALLATION MENU PAGE 8 – NAV CONFIG

RS-232 GPS navigator config.

INSTALLATION MENU PAGE 9 – ACU CONFIG

ACU config for FD and HDG/CRS Datum.

INSTALLATION MENU PAGE 10 – RSM Calibration

RSM magnetometer calibration.

INSTALLATION MENU PAGE 11 – ACCEL BIAS CAL

Factory calibration page.

EFD1000 CONFIGURATION CHART

RSM Calibration

Calibration Overview

Overview of RSM calibration procedure.

Conventional Gear RSM Calibration Procedure

Calibration for conventional gear aircraft.

RSM Calibration Procedure

Detailed RSM calibration steps.

Heading Offset Adjustment

Heading offset adjustment for PFD software.

Heading Accuracy Test

Final heading accuracy check.

Heading Interference Test

Heading interference testing.

Ground Test Procedure

Post Installation Flight Check

Basic ADI Flight Checks

Flight checks for Attitude Director Indicator.

Basic HSI/DG Flight Checks

Flight checks for HSI/DG.

ILS Flight Checks

ILS approach checks.

Autopilot Flight Checks (if installed)

Autopilot checks with EFD1000.

Operation

Pilot Controls

Pilot interface overview.

Power Control

EFD1000 internal battery and power management.

Display and Control Layout

Identification of display and control features.

Control Knobs

Operation of control knobs.

Setting Flight Instruments

Procedures to set flight instrument data.

Knob Sync Function

Synchronizing editable fields via knobs.

Hot Key Operation

Function of soft keys (Hot Keys).

Tapes

Airspeed and altitude tape control.

Minimums

Minimums display and alerts.

Compass Presentation Format

Compass display modes.

Basemap and Declutter Level

Basemap symbology control.

GPSS (PRO model)

GPSS enable/disable.

CDI and Bearing Pointer Source Selection

Selecting navigation sources.

Back Light Control

Backlight adjustment.

Primary Flight Instruments

Primary flight instrument displays.

Bearing Pointers

Bearing pointer general description.

Situational Awareness Map Display

Basemap display.

Autopilot Integration

Autopilot system compatibility.

Main Menu

Main Menu controls and navigation.

Menu Options

General settings options.

V-Speed Setting Pages

V-Speed marker settings.

Power Settings Page

Power source monitoring and control.

System Status

System and software status.

Environmental Qualification Forms

APPENDIX A TROUBLESHOOTING

APPENDIX B INSTALLATION FINAL CHECK SHEET

APPENDIX C OPERATOR CONFIGURATION CHECKLIST

APPENDIX D INSTRUCTIONS FOR CONTINUED AIRWORTHINESS

D.1 Introductory Information

Maintenance instructions and required data.

D.2 System Description

Description of EFD1000 components.

D.3 System Operation

Reference to operation manuals.

D.4 Servicing

Statement on field serviceability.

D.5 Overhaul Period

Overhaul period information.

D.6 Special Tools

Reference to special tools.

D.7 Airworthiness Limitations

Airworthiness maintenance requirements.

D.8 Distribution of Revisions

Revision distribution information.

D.9 Periodic Maintenance and Calibration

Maintenance and calibration guidance.

D.10 Unit and Wiring Inspection

Annual inspection of units and wiring.

D.11 Troubleshooting

Reference to troubleshooting appendix.

D.12 Removal and Replacement

Instructions for LRU removal and replacement.

Related product manuals

Aspen Avionics EFD1000 E5

226 pages

Aspen Avionics EFD1000 Dual EFI

163 pages

Evolution EFD1000 PFD

174 pages

Evolution EFD1000 VFR PFD

228 pages

EVOLUTION EFD1000 PRO MAX PFD

179 pages

Aspen Avionics EFD1000 User Manual

Table of Contents

Other manuals for Aspen Avionics EFD1000

Questions and Answers:

Aspen Avionics EFD1000 Specifications

Summary

Special Notes to the Installer

Document Revisions

Introduction

Part Numbers

Authorized Configurations

Installation Kit Contents

Accessories Required but Not Supplied

Optional Accessories Not Supplied

Special Tools Required

Vendor Information

Warranty Registration

Regulatory Compliance

Equipment Specifications and Limitations

Primary Flight Display (PFD) & Configuration Module (CM)

Remote Sensor Unit (RSM)

Analog Converter Unit (ACU)

System Description

Primary Flight Display (PFD)

Remote Sensor Module (RSM)

Configuration Module

Analog Converter Unit (ACU)

System Architecture

Supported Installed Configurations

Pilot Configurations

Pro Digital Configuration

Pro Configurations with Autopilot

Pro Configuration with Autopilot and Digital/Analog VLOC

Pro Configuration with Autopilot and Dual Analog VLOC

Pre Modification Planning

Pre Modification Checklist

Requirements and Limitations

Standby Attitude Positioning

Standby Airspeed and Altimeter Positioning

Directional Gyro/ HSI

Back Up Nav Indicator

Aircraft Power Requirements

EFD1000 Power Requirements

Special Considerations for Aircraft Limited to VFR

Optional Interfaces

Autopilot

GPS Navigator Basemap Compatibility

GPSS

GPS/ NAV Switching

Heading Output

Flush or Recess Mounting the PFD

Mechanical Installation

Unpacking and Inspecting Equipment

Equipment Location Documentation

Weight and Balance

Installation Limitations

Equipment Bonding

Cooling

PFD Installation

Connecting the Internal Battery

PFD Mounting Location

Mounting Bracket Installation

PFD Bonding Strap

RSM Installation

Proposed RSM Location Check

Pressurized Aircraft

RSM mounting on Composite or Fabric

RSM Mounting Angles

RSM Doubler

RSM Doubler Fabrication

RSM Installation

RSM Shim Fabrication (if necessary)

ACU Installation

ACU Mounting

Configuration Module Installation

Electrical Installation

Electrical Load Analysis

Electrical Installation

HIRF/Lightning Requirements

PFD to GPS/VLOC/ACU Wiring
