Navigator Navigator Mode
and/or
Type of Connection
EFD1000 Mode
and/or
Type of Connection
Basemap Depiction
Garmin GNS-400
Series
RS-232 This configuration
should not be used.
This connection method can incorrectly
display curved segments as straight lines
and the displayed information can be
misleading to the pilot in certain
conditions.
Garmin GNS-480 Standard Mode, RS-
232
Normal Mode, RS-
232
This connection method presents straight-
leg portions of flight plans. An open
segment is shown in lieu of a curved
segment.
Garmin GNS-480 ARINC 429
“GAMA 429 no FP”
configuration only
ARINC 429 Certain flight plan labels are missing from
the GNS-480 ARINC 429 output, so
connection will result in no flight plan data
on the EFD 1000 display. All other
functions are operational. No other
GNS480 “CH_OUT” configurations should
be used.
Garmin GNS-500
Series
ARINC 429 ARINC 429 This connection method presents curved
approaches.
Garmin GNS-500
Series
RS-232 This configuration
should not be used.
This connection method can incorrectly
display curved segments as straight lines
and the displayed information can be
misleading to the pilot in certain
conditions.
Trimble
TNL-2000
TNL-3000
RS-232 This configuration
should not be used.
This connection method can incorrectly
display the map information.
Table 5.2 – GPS Navigator Basemap Compatibility
Other GPS navigators have not been evaluated and may be compatible. Contact Aspen
Avionics for information regarding additional navigators.
