CHAPTER 4 REFERENCE GUIDE
EFD1000 VFR PFD Pilot’s Guide
Page 4-25
091-00028-001 ( )
The ARC CDI Compass Mode uses a xed CDI, resembling a contemporary GPS
navigation deviation display. The ARC CDI Compass Mode is intended to maximize the
lower display area for map and ight plan data (Figure 4-42).
Figure 4-42
ARC CDI Compass Mode
