Specifications
Model
CCM-iBIS
Main body
External dimensions
530 mm (W) x 860 mm (D) x 381 mm (H) *Projections included
Number of settable dishes
9 (60-mm µDROP GPS Dish)
Inside-chamber dimensions
72 mm (W) x 84 mm (D) x 18 mm (H) Capacity: Approx. 108 ml
Humidification method
Non humidification / Dry (Culture) System
Power supply
AC 110 V/115 V, AC 220-240 V, 50/60 Hz
Weight of the main body
Approx. 56 kg
Temperature control
Temperature control method
Digital PID method, independent control of each incubation
chamber
Operational temperature range
24ºC to 28ºC
Temperature control range
36ºC to 39ºC
Temperature fluctuation range
±0.1ºC (room temperature: 26ºC)
Temperature distribution
±0.1ºC (room temperature: 26ºC)
Main heater
Silicon rubber heater
Gas specifications
CO
2
sensor
Infrared CO
2
sensor
CO
2
control method
Duty control
CO
2
control range
0 to 20% CO
2
CO
2
fluctuation range
±0.1% CO
2
O
2
sensor
Ceramic O
2
sensor
O
2
control method
Duty control
O
2
control range
2 to 18% O
2
O
2
fluctuation range
±0.5% O
2
XY stage
Shift range
±100 mm (x axis), ±150 mm (y axis)
Resolution
12 µm/step
Maximum speed
30 mm/second or more
Repetitive-positioning
accuracy
Within ±10 µm
Z stage
Shift range
±5 mm
Resolution
0.5 µm/step
Maximum speed
5 mm/second
Repetitive-positioning
accuracy
Within ±0.3 µm
Optical
system
Camera
1.3-million pixel CCD camera, 4.86 mm x 3.62 mm imaging size
Objective lens
Objective lens (10X) for biological microscopes (Monitor display
magnification: Approx. 320 times)
Light source for illumination
Red LED (Peak wavelength: 623 nm)
Image save format
JPEG format
Image save method
NAS (Mirroring function equipped, 4TBx2)
External
output
Analog output
Temperature (9 incubation chambers), CO
2
concentration,
O
2
concentration
Contact output
Close when an alarm is sounded; close when power is turned Off
