ASTEC CCM-iBIS - File; Export Files (Image File Transfer)

46
PC Operations - File Transfer
2-12 File
2-12-1 Export Files (Image file transfer)
Use when transferring captured images to an external location. File transfer is to be performed for
each sample.
Touching the Export Files radio button makes switches the display to the Export Files screen.
Enter a transfer destination directory into field , or touch button and then use the browse
dialog to specify a directory. To create a new folder, touch button , use the browse dialog to
specify a directory, enter a new folder name into field , and then touch New Folder .
With Patient Name or Patient ID , select the name or ID of the sample to be transferred.
To delete the original image files after transfer, check the checkbox for Delete Exported Files .
Removable HDD: Removes a USB-connected external storage device.
EXPORT: Executes image file transfer.
CANCEL: Restores the Main window without executing transfer.
